| Technical Specifications – Camera |
|
| Image Sensor |
1/2.8-inch Exmor CMOS, 2.14MP |
| Supported Resolutions |
1080p/60, 1080p/30, 1080i/60, 720p/60, 720p/30, 1080p/50, 1080p/25, 1080i/50, 720p/50, 720p/25 |
| Focal Length |
f = 4.7–94.0mm |
| Iris |
F1.6–F3.5 |
| Optical Zoom |
20× |
| Digital Zoom |
12× |
| Shortest Focus Distance |
10–1,000mm |
| Field of View |
59.5° to 2.9° |
| Minimum Illumination |
0.5 lux (color), 0.1 lux (B/W) |
| Shutter Speed |
1/1 to 1/10,000 sec |
| AGC |
Auto/manual |
| White Balance |
Auto, indoor, outdoor, One Push, manual, auto tracking |
| AE Control |
Auto, manual, shutter priority, iris priority |
| S/N Ratio |
≥50dB |
Pan & Tilt |
|
| Pan Range |
-170° to +170° |
| Tilt Range |
-30° to +90° |
| Pan Speed |
0.1° to 120°/s |
| Tilt Speed |
0.1° to 90°/s |
| Preset Number |
256 |
| OSD |
Available |
| Image Flip |
Enabled |
Network |
|
| Maximum Image Size |
1920 × 1080@60fps |
| Video Compression |
H.265, H.264 |
| Audio Compression |
AAC |
| Protocol |
HTTP, RTP, TCP, UDP, RTSP, RTMP, ONVIF |
| Network Support |
Dual stream; up to 10 simultaneous users |
Interface |
|
| Ethernet |
RJ45, 100M |
| Video Output |
HD-SDI |
| Control Interface |
RS-232, IR, RS-485 |
General |
|
| Control Protocol |
VISCA with daisy-chain capability, Pelco-P, Pelco-D |
| Address |
0–63 |
| Power Supply |
DC 12V |
| Power Consumption |
<15W |
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-20°C to 60°C |
| Dimensions |
8.9 × 6.2 × 8.1 in |
| Enclosure |
Gray |
| Weight |
1.7 kg |
Warranty |
|
| Warranty |
5 Years |
