| Connections |
|
| Inputs |
1 × HDMI In |
| Outputs |
1 × HDBaseT RJ45 |
| Connector Type(s) |
Tx: 2 × USB-A Charging Ports |
Performance |
|
| Distance |
4K60 4:2:0 @ 130 ft / 40 m |
| Video Support |
4K2K@60Hz 4:2:0, 4K2K@30Hz 4:4:4 |
| Compliance |
HDMI 2.0, HDCP 2.2 |
| Main Power |
RX: 100–240VAC, 50/60Hz; TX: Powered by RX via PoC |
| Power Adapter |
24VDC CE/FCC/UL Power Adapter |
| Power Consumption |
7.5 Watts |
| Power Supply |
100–240VAC, 50/60Hz |
| Operating Temperature |
0° to 40°C |
| Storage Temperature |
-20° to -60°C |
| Relative Humidity |
20–90% RH, non-condensing |
| ESD Protection |
Human Body Model ±8kV air discharge and ±4kV contact discharge |
Enclosure |
|
| Product Dimensions |
RX: 2.56 in × 3.48 in × 0.79 in |
| Product Weight |
RX: 0.36 lbs |
| Product Dimensions |
TX: 4.13 in × 3.61 in × 1.57 in |
| Product Weight |
TX: 0.47 lbs |
Warranty |
|
| Warranty |
5 Years |
