| Performance |
|
| Distance |
330 ft. / 100 m |
| Resolutions |
Up to 4K@50/60Hz (4:4:4) |
| Compliance |
HDMI 2.0b, HDCP 2.2/1.4 |
| Data Transfer Rate |
18 Gbps |
| Color Space |
RGB/YCbCr 4:4:4, YCbCr 4:2:2 |
| Color Depth |
8-bit, 10-bit, 12-bit |
| Supported HDMI Audio Formats |
LPCM 2/5.1/7.1 CH, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X |
| Control Options |
RS-232, IR |
| Power Consumption |
11 Watts max |
| Power Supply |
Input: AC100–240V, 50/60Hz; Output: DC 24V/1A (US/EU standards, CE/FCC/UL certified) |
| Operating Temperature |
32° to 104°F / 0° to 40°C |
| Storage Temperature |
-4° to 148°F / -20° to 60°C |
| Relative Humidity |
20–90% non-condensing |
| MTBF |
50,000 hours |
| Video Output Format |
1 × HDMI Type A [19-pin female], 1 × IR [3.5mm stereo mini-jack], 1 × LAN [RJ45] |
Enclosure |
|
| Enclosure Type |
All metal, black powder coat finish |
| Product Dimensions |
6.7 × 3.8 × 0.7 in |
| Product Weight |
0.94 lbs |
Warranty |
|
| Warranty |
Limited Warranty, 3 Years |
