| Performance |
|
| Supported Distance |
Up to 230 ft / 70 m at Ultra HD/4K; up to 330 ft / 100 m at 1080p |
| Supported Resolutions |
Ultra HD/4K up to 4096 × 2160@50/60Hz (RGB 4:4:4; YCbCr 4:4:4, 4:2:2, 4:2:0) |
| Compliance |
HDMI 2.0, HDCP 2.2 |
| Video Bandwidth |
18 Gbps |
| RS-232 |
1 × RS-232 via Phoenix connector |
| IR Extension |
1 × IR input via 3.5mm stereo mini-jack, 1 × IR output via 3.5mm stereo mini-jack |
| Power Consumption |
24W max |
| Power Supply |
DC 24V/1A, US/EU standard, CE/FCC/UL certified |
| Operating Temperature |
32° to 117°F / 0° to 47°C |
| Storage Temperature |
-4° to 140°F / -20° to 60°C |
| Relative Humidity |
0–90% non-condensing |
| MTBF |
50,000 hours |
Enclosure |
|
| Product Dimensions |
7.2 × 3.5 × 0.7 in / 183 × 88 × 18 mm |
| Product Weight |
1.0 lb / 0.45 kg |
Warranty |
|
| Warranty |
Limited Warranty, 3 Years |
