| Performance |
|
| Supported Distance |
Up to 130 ft / 40 m at Ultra HD/4K; up to 230 ft / 70 m at 1080p |
| Supported Resolutions |
4K@50/60Hz (4:2:0), 4K@30Hz (4:4:4), 1080p@120Hz, 1080p 3D@60Hz |
| Compliance |
HDMI 1.4, HDCP 2.2, USB 2.0 |
| Data Transfer Rate |
18 Gbps |
| Video Bandwidth |
10.2 Gbps |
| RS-232 |
1 × RS-232 via 3-pin Phoenix connector |
| Power Consumption |
9W |
| Power Supply |
DC 24V/1A, US/EU standards, CE/FCC/UL certified, via 2-pin Phoenix connector |
| Operating Temperature |
32° to 117°F / 0° to 47°C |
| Storage Temperature |
-40° to 158°F / -40° to 70°C |
| Relative Humidity |
0–90% non-condensing |
| MTBF |
50,000 hours |
Enclosure |
|
| Product Dimensions |
TX: 4.0 × 1.8 × 1.2 in; RX: 5.6 × 2.9 × 0.9 in |
| Product Weight |
TX: 0.36 lbs; RX: 0.44 lbs |
| Product Dimensions |
12.21 × 7.09 × 2.76 in / 310 × 180 × 70 mm |
| Product Weight |
7.7 lbs / 3.5 kg |
Warranty |
|
| Warranty |
Limited Warranty, 3 Years |
