| Connections |
|
| Inputs |
TX: 1 × HDMI IN [Type A, 19-pin female]; RX: 1 × Optical Fiber IN [LC female] |
| Outputs |
TX: 1 × HDMI OUT, 1 × Optical Fiber OUT; RX: 1 × HDMI OUT [Type A, 19-pin female] |
| Control Ports |
2 × IR IN [3.5mm stereo mini-jack], 2 × IR OUT [3.5mm stereo mini-jack], 1 × RS-232 IN/OUT [3.81mm Phoenix connector] |
| Audio Input Type(s) |
TX: 1 × LINE IN [3.5mm stereo mini-jack] |
| Audio Output Type(s) |
RX: 1 × Audio OUT [3.5mm stereo mini-jack] |
Performance |
|
| Distance |
Up to 10 km / ~33,000 ft over single-mode fiber cable |
| Resolutions |
Up to 4K2K@60Hz 4:4:4 |
| Compliance |
HDMI 2.0b, HDCP 2.2, DVI 1.0 |
| Color Space |
RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0 |
| Color Depth |
8-bit, 10-bit, 12-bit, HDR |
| Supported HDMI Audio Formats |
LPCM 2/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby TrueHD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD |
| RS-232 Baud Rate |
4800–115200 bps |
| Power Consumption |
TX: 3.85W max; RX: 2.7W max |
| Power Supply |
Input: AC 100–240V, 50/60Hz |
| Power Supply Output |
Output: DC 5V/1A |
| Operating Temperature |
32° to 104°F / 0° to 40°C |
| Storage Temperature |
-4° to 140°F / -20° to -60°C |
| Relative Humidity |
20–90% non-condensing |
| HDMI/DP/VGA Version |
HDMI 2.0b |
| ESD Protection |
±8kV air-gap discharge and ±4kV contact discharge |
Enclosure |
|
| Product Dimensions |
TX/RX: 134mm × 68mm × 18mm |
| Product Weight |
TX: 280g; RX: 278g |
Warranty |
|
| Warranty |
3 Years |
