4K60 HDMI™ to 1 LC Fiber Transmitter for Media Axis™ 2

MAX2 Transmitters

4K60 HDMI™ to 1 LC Fiber Transmitter for Media Axis™ 2

Name: 4K60 HDMI™ to 1 LC Fiber Transmitter for Media Axis™ 2
Brand: PureLink
SKU: MAX2-FT100
Price: 2200.00 USD
Availability: InStock

MAX2-FT100

TAA

Contact us Find a dealer Test drive this product

Category	Title	Version	Updated	Download
Product Sheet	MAX2-FT100 — Product Sheet	3.0	08-19-2026	Download
Others	Media Axis vs. Media Axis 2 (MAX2) — Comparison Chart	1.0	08-19-2026	Download
User Manual	MAX2 — User Manual	2.1	08-19-2026	Download
Application Diagram	MAX2 — Multiview Application Diagram	5.5	08-19-2026	Download
Application Diagram	MAX2 — Dante Application Diagram	2.0	08-19-2026	Download
Product Catalog	MAX2 — Product Catalog	1.0	08-17-2026	Download
Product Catalog	TAA — Product Catalog	1.2	08-17-2026	Download

Connections
Inputs	1 × HDMI with Deep Color, 3D, and 4K
Outputs	HDBaseT™ 3.0 with Deep Color, 3D, and 4K
Connector Type(s)	1 × HDBaseT™ 3.0 port, 1 × Female HDMI port, 1 × 3-pin Phoenix connector for audio insertion
Performance
Distance	330 ft / 100 m
Resolutions	Up to Ultra HD/4K (4096 × 2160, 4:4:4@50/60Hz)
Supported Digital Audio Formats	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, DTS, DTS-ES, DTS 96/24, DTS-HD High Resolution, DTS-HD Master Audio, LPCM up to 8 channels
Compliance	HDCP 2.2
Data Transfer Rate	18 Gbps
Power Consumption	DC 12V or PoE injector, 10W max
Power Supply	100–240VAC, 50/60Hz
Power Injection for CATx Extenders	PoE injector
Operating Temperature	32° to 117°F / 0° to 47°C
Storage Temperature	-40° to 158°F / -40° to 70°C
Relative Humidity	0–90% non-condensing
Enclosure
Product Dimensions	1.94 × 3.06 × 4 in / 49 × 78 × 102 mm
Product Weight	1 lb / 0.45 kg
Shipping Dimensions	15 × 15 × 4 in / 381 × 381 × 101 mm
Shipping Weight	2 lbs / 0.91 kg
Warranty
Warranty	3 Years, Parts and Labor
