| Hardware |
|
| Input Signal Type(s) |
1 × 3G-SDI, 1 × HDMI Type A female, 1 × AUX output via female BNC, 1 × 3.5mm audio output, 1 × L/R RCA audio input |
| Output Signal Type(s) |
1 × 3G-SDI, 1 × HDMI Type A female, 1 × AUX output via female BNC, 1 × 3.5mm audio output, 1 × L/R RCA audio input |
Performance |
|
| Distance |
330 ft / 100 m at 1920 × 1200@60Hz, 1080p, or Ultra HD 4K |
| Resolutions |
480i/576i, 480p/576p, 720p, 1080i, 1080p@60Hz, 1920 × 1080, 1680 × 1050, 1600 × 900, 1440 × 1050, 1366 × 768, 1360 × 768, 1280 × 1024, 1280 × 960, 1280 × 800, 1280 × 768, 1280 × 720, 1280 × 600, 1152 × 864, 1024 × 768, 800 × 600 |
| Data Transfer Rate |
3.4 Gbps per channel, 10.2 Gbps total max |
| Compliance |
DVI 1.0, HDMI 1.4b, HDBaseT |
| HDCP Compliance |
HDCP 2.0 |
| Power Consumption |
10W max |
| Power Supply |
DC 12V |
Connections |
|
| Connector Type(s) |
1 × DVI 29-pin/HDMI 19-pin female, 1 × 3.5mm stereo jack, 1 × RJ45 jack, 1 × 3-pin 3.5mm terminal block for power, 1 × 3-pin 3.5mm terminal block for RS-232 |
Enclosure |
|
| Product Dimensions |
5.75 |
Warranty |
|
| Warranty |
5 Years |
