| Hardware |
|
| Input Signal Type(s) |
Combined digital video and audio signal via HDMI |
| Output Signal Type(s) |
Digital video via DVI, digital audio via S/PDIF |
Performance |
|
| Supported Resolutions |
VGA–WUXGA, 480p–1080i/p |
| Power Consumption |
DC 5V power adapter included, 5W max |
| Power Supply |
100–240VAC, 50/60Hz |
| Operating Temperature |
32° to 117°F / 0° to 47°C |
| Storage Temperature |
-40° to 158°F / -40° to 70°C |
| Relative Humidity |
0–90% non-condensing |
| MTBF |
50,000 hours |
| Rack Mounting Option |
Standard rack-mountable design |
| Receptacle |
DC power jack, HDMI 19-pin female, DVI 29-pin female; interface: HDMI 1.3, DDWG DVI 1.0 |
Enclosure |
|
| Rack Mounting Option |
Standard rack-mountable design |
| Product Dimensions |
90 × 103 × 30 mm |
| Product Weight |
0.3 kg |
Warranty |
|
| Warranty |
Limited Warranty, 3 Years |
