The PS-820S is an 8×2 seamless presentation switcher with 18 Gbps support, true 4K60 4:4:4 instant switching, and individual video scaling for each output bus. The PS-820S features flexible input options including HDMI, HDBaseT, DisplayPort, and USB-C, as well as balanced audio embedding and audio mixing via S/PDIF. Together with convenient control options including relay control, the PS-820S provides a feature-rich solution for conference rooms, home theaters, broadcast studios, hotel AV, auditoriums, and staging/rental environments that require seamless 4K60 video and audio distribution.

Couple the PS-820S with our iCON Control System for easy implementation of video, audio, IR, and RS232 matrixing and control of your space.

• 4K60 4:4:4 with Don’t Blink™ Switching Technology
• (8) inputs including HDBaseT, HDMI, DisplayPort, and USB-C
• Audio embedding and mixing with volume control via balanced audio inputs
• HDCP 2.2 compliant
• Complete EDID management for individual inputs
• CEC control
• Proprietary Precis codec for lossless video transmission
• HDBaseT Distance: 40m@4K and 70m@1080p
• Auto-switching on HDMI and HDBaseT outputs
• Audio de-embedding with volume control via balanced analog and S/PDIF audio outputs
• Local/pass-through IR and RS-232, TCP/IP, relay, CEC and OSD

Specifications
