The VIP-300H-U 4K HDMI & USB/KM over IP Extension System provides Ultra HD/4K video, audio, RS-232, IR, and USB signal extension, point to point, with or without a network. The Transmitter can be connected to a Receiver supporting distances up to 390 ft. (120 meters), or through a network switch, effectively doubling the extension distance up to 240 meters. Video over IP extension, when utilized on a network, allows you to convert your extension system at any time to distribution, switching, or matrix routing, a major advantage of Video over IP opposed to other technologies.

Key Features

• Ultra HD – 4K/30 4:4:4, 4K/60 4:2:0 (converted to 4K30)
• Use as Fiber or CAT extender (SFP modules optional)
• Extend up to 120 meters TX direct to RX, or 240 meters TX to network switch to RX
• PoE (802.3af) powered TX and RX when extending over network
• Extend 4K30 video, and stereo or multi-channel audio
• Digital and Analog Audio Insertion/Extraction
• Extend keyboard, mouse, touchscreen, and more via USB 2.0
• Extend RS232, and Infrared
• Utilize built-in API diagnostics of TX, RX, source, and display when extending through network
• Settable scaler in RX with image rotation options
• Can be converted with additional Tx/Rx units for distribution, switching, and matrix systems
• HDCP 2.2 Compliant

Specifications
